front and RHS engine
crankshaft pulley old and new showing 22 degree offset
oil filter assy parts
oil filter plate with eclip
oil filter using filter to press plate down to secure eclip
  oil fliter eclip in place.JPG - The e-clip in place. I thought it would be hard, it wasn't. I forgot to take pictures, so Laura suggested I take it all apart and snap these the second time around. She was present because I was using the auto restoration surface in the kitchen, where other auto restoration tools are available, such as an oven, a hot water parts cleaner, and an assortment of pans and containers.
oil filter assy ready edge polished
oil filter installing thinest gasket on block
oil filter screws on by hand with eclip providing tension
OIl Pressure check with battery set up
No Pressure

39 | The e-clip in place. I thought it would be hard, it wasn't. I forgot to take pictures, so Laura suggested I take it all apart and snap these the second time around. She was present because I was using the auto restoration surface in the kitchen, where other auto restoration tools are available, such as an oven, a hot water parts cleaner, and an assortment of pans and containers. Download
